Automatic Sticker Labelling Machine
– For Ampoules

Laxmi Pharma Equipment is one of the leading manufacturers and exporter and Supplier of Automatic Sticker Labelling Machine – For Ampoules.

Labelling glass ampoules that have been previously filled and sealed is possible with the help of Laxmi Pharma Equipment's Automatic High Speed ampoule Sticker Labelling Machine (Model: LASL series) and Vertical Linear Sticker Labelling Machine. The machine's ability to operate at a minimum necessary output of 250–300 labels per minute, depending on the label size and quality, is an extra benefit for customers who want to use servo or stepper motors powering the machine. With very few tools needed, all of the modifications are quite user-friendly.

WORKING PRINCIPLE

Automated Labelling using sticker ampoule machines is vital in the pharmaceutical industry, where accuracy and security are paramount. These devices increase productivity, save human labor, and eliminate labeling mistakes, guaranteeing proper presentation of ampoules’ vital information without jeopardizing the fragile vials’ integrity.

Ampoules, which are small sealed vials containing liquid medication, are usually loaded onto a conveyor system. This conveyor carefully transports the ampoules to the labeling station. A roll of adhesive labels is loaded onto the label dispenser of the machine. These labels are typically made of thin paper or plastic and come on a continuous roll. The machine unwinds the label roll, and a sensor detects the gaps or notches between individual labels.

APPLICATIONS

Pharmaceutical

Food & Beverages

Cosmetic

pesticides

chemical

SALIENT FEATURES

Product Images

TECHNICAL SPECIFICATION

Model No.LASL 80LASL 100LASL 150LASL 200
Label Height10mm to 45mm10mm to 90mm10mm to 90mm10mm to 90mm
Label Length10-25mm10-25mm10-25mm10-25mm
Gap Between two labelsMinimum 3-5mmMinimum 3-5mmMinimum 3-5mmMinimum 3-5mm
Label Roll Dia.StandardStandardStandardStandard
Power Characteristics220v, 1 Phase, 50Hz, 1.2kw220v, 1 Phase, 50Hz, 1.2kw220v, 1 Phase, 50Hz, 1.2kw220v, 1 Phase, 50Hz, 1.2kw
Output / minute60-80 labels/minute80-100 labels/minute140-150 labels/minute180-200 labels/minute
Conveyor Length1500 – 1800mm1500 – 1800mm1500 – 1800mm1500 – 1800mm
